{tab=Specification}
| Model | Suitable Dia. Of pipeline | Shrink Sleeve OD (mm) | Sleeve Thickness (mm) | Heat-Melt Adhesive Thickness(mm) |
| BH-FRY Φ114*500-1.2/0.8 | Φ114 | 154 | 1.2 | 0.8 |
| BH-FRY Φ159*500-1.2/0.8 | Φ159 | 209 | 1.2 | 0.8 |
| BH-FRYΦ219*500-1.2/0.8 | Φ219 | 269 | 1.2 | 0.8 |
| BH-FRYΦ273*500-1.2/0.8 | Φ273 | 323 | 1.2 | 0.8 |
| BH-FRYΦ325*500-1.2/0.8 | Φ325 | 375 | 1.2 | 0.8 |
| BH-FRYΦ377*500-1.2/0.8 | Φ377 | 427 | 1.2 | 0.8 |
| BH-FRYΦ426*500-1.5/0.8 | Φ426 | 476 | 1.5 | 0.8 |
| BH-FRYΦ529*500-1.5/0.8 | Φ529 | 579 | 1.5 | 0.8 |
| BH-FRYΦ630*500-1.5/0.8 | Φ630 | 680 | 1.5 | 0.8 |
| BH-FRYΦ720*500-1.5/0.8 | Φ720 | 770 | 1.5 | 0.8 |
| BH-FRYΦ813*500-1.5/0.8 | Φ813 | 863 | 1.5 | 0.8 |
| BH-FRYΦ920*500-1.5/0.8 | Φ920 | 970 | 1.5 | 0.8 |
| BH-FRYΦ1016*500-1.5/0.8 | Φ1016 | 1066 | 1.5 | 0.8 |
| BH-FRYΦ1220*500-1.5/0.8 | Φ1220 | 1270 | 1.5 | 0.8 |
| BH-FRYΦ1350*500-1.5/0.8 | Φ1350 | 1400 | 1.5 | 0.8 |
Remarks:
1. The above data is normal size. We can produce certain size of products according to the customers’ demand.
2. The matching accessories: Epoxy primer, Curing agent, Brush, Glove, Mix rod.
{tab=Technical Data}
| No. | Item | Unit | Test results | Test Method | Conclusion | |
| 1 | Tensile strength | MPa | 24.6 | GB/T 1040.2/ASTM D638 | Pass | |
| 2 | Ultimate Elongation | % | 640 | GB/T 1040.2/ASTM D638 | Pass | |
| 3 | Electric strength | MV/m | 32.3 | GB/T 1408.1/ASTM D149 | Pass | |
| 4 | Volume Resistivity | Ω·m | 6.05×1013 | GB/T 1410/ASTM D257 | Pass | |
| 5 | chemical corrosion resistance 10% HCl （7d） 10% NaOH （7d） 10% NaCl （7d） |
% % % |
98 98 98 | GB/T23257-2009 Appendix H | Pass | |
| 6 | Heat Aging（150℃21d） (%Elongation) | % | 554 | GB/T 1040.2/ASTM D638 | Pass | |
| 7 | Heat Shocking (225℃,4h) | － | No cracking, flow, or dripping | GB/T23257-2009 Appendix L/ASTM D2671 | Pass | |
| 8 | Impact Resistance | J | ＞15 | GB/T23257 Appendixk/ ASTM G14 | Pass | |
| 9 | Softening point of adhesive | ℃ | 115 | GB/T 4507 | Pass | |
| 10 | Lap Shear Strength | KPa | 2053（23℃） | GB/T 7124/ASTM D1693 | Pass | |
| 320（70℃） | ||||||
| 11 | Peel strength | PE/FBE | N/cm | 191（23℃） | Pass |
Pass
|
| 24（70℃） | ||||||
| PE/PE | 185（23℃） | |||||
| 23（70℃） | ||||||
| PE/Steel | 166（23℃） | |||||
| 22（70℃） | ||||||
| 12 | Cathodic Disbondment | mm | 16.5 31.2 | ASTM G42 ASTM G8 | Pass | |
| 13 | （70℃，120d） Hot-Water Immersion | － | No delamination, blisters,or water under strap | GB/T23257 AppendixN/ASTM B870 | Pass | |
| 14 | Water Absorption | ％ | 0.05 | SY/T0447/ASTM B570 | Pass | |
| 15 | Low-Temperature Flexibility | － | -15℃Min | ASTM D2671 | Pass | |
